Description
For Torque Control applications
Precision torque control with up to 250 μs update rate. Sensorless control of induction, permanent-magnet and hybrid PM motors. 98% efficient, minimal energy lost during the power conversion process. Easy common DC bus configuration, dynamic braking, and regenerative mode. Full spectrum of stand-alone, modular and pre-assembled drives up to 2.8MW (4,200hp). On-board PLC to execute programs for logic and sequencing
For Speed Control applications
Fully configurable S-ramps High bandwidth speed loop and switching frequencies supported up to 16 kHz Built-in, universal feedback interface supporting everything from resolvers to incremental and absolute encoders Stationary autotune Low acoustic noise due to adjustable multi-speed fan and intelligent thermal management Integrated Safe Torque Off (STO) input(s), certified to SIL3 / PLe
For Position Control applications
Support for virtually all control bus technologies, including traditional fieldbuses and serial communications Effortless integration into PLC architectures with PLC Controlled Motion Built-in, 1.5 axis advanced motion controller with cam profiles, homing, and electronic gearbox Scalable integrated motion control reduces demand on, or can entirely replace, a central PLC Comprehensive motion safety functions, including over safe networks
Conform to safety standards by direct safety system integration
All Unidrive M drives have integrated Safe Torque Off (STO) inputs, certified to SIL3 / PLe, providing an elegant and reliable safety solution.
